ELISA HCM100-Pro Thermo Mix
FµLly programmable Mixing
Precise temperature control for heating and cooling
Real-time display of speed, temperature and time
Excellent mixing (200-1500rpm)
Quick interchange of blocks without tools and automatic block recognition via magnetic attachment between block and base
Compatible with all popµLar tubes
Block equipped with a lid for heat preservation and evaporation buildup
Temperature self-calibration
One defaµLt heating block is included -you specify!
Adaptors and Accessories
See all heating blocks and accessories -see the pictures as well as this attached description on adaptors and accessories, download here.
Specifications
Parameter
Value
Temperature range
Below room temp 15-100℃
Temperature Setting range
0-100℃
Temperature control accuracy@20-45
±0.5℃
Temperature uniformity@20-45
±0.5℃
Time setting range
0min-99h30min
Max Heating speed
5.5℃/min
Max Cooling speed
5℃/min(100℃-room temp) 0.5℃/min below room temp)
Functions
Heating/cooling/mixing
Mixing speed
200-1500rmp
Mixing orbit
3mm
Program memory
9
Overheating protection
150℃
Power
200W
Display
TFT
Voltage/Frequency
110/220V,50/60Hz
Dimension[WxDxH]
200x235x120mm
Weight
7.3kg
Permissible ambient temperature
10-40℃
Permissible ambient humidity
<80% RH
